射出成形機排出油圧シリンダー

射出成形機の排出油圧シリンダーは、射出成形機の非常に重要な部分です。注入が完了し、金型が開かれると、エジェクターの油圧シリンダーは、油圧式の力を介してエジェクターロッドまたはエジェクターブロックを押して、カビから射出成形生成物を排出し、産物の摂取を容易にします。

製品説明

The injection molding machine ejection hydraulic cylinder function: drives the injection platform to move.

Bore diameter 63mm～140mm

Rod diameter 36mm～90mm

Stroke≤1500mm

Thrust: Maximum 384KN

(Bore diameter 140mm/pressure 25MPa)

cast steel ZG270-500, cast steel ZG310-5, alloy steel 18MnMoNb, 45# steel ingot forging, 42CrMn overall forging

Japan NOK, Parker oil seal, American MPI, Swedish SKF, Austrian polyurethane oil seal, customer-specified brands are accepted.

1. Customized rated ejection pressure is large to ensure efficient demoulding.

2. Accept OEM&ODM services.

3. Made of alloy steel 18MnMoNb, 45# steel and other materials, durable.

4. Imported seals from Japan and the United States guarantee excellent sealing performance.

5. Easy to install, suitable for various injection molding machine models, and can accept any form of customization.
